58183 Solid Carbide (Brazed To Steel Shank) Spiral Flush Trim Compression 3/4 Dia x 1-1/8 x 1/2 Inch Shank With Upper And Lower Ball Bearings

Amana 58183 Solid Carbide (Brazed To Steel Shank) Spiral Flush Trim Compression 3/4 Dia x 1-1/8 x 1/2 Inch Shank With Upper And Lower Ball Bearings

Name: Amana 58183 Solid Carbide (Brazed To Steel Shank) Spiral Flush Trim Compression 3/4 Dia x 1-1/8 x 1/2 Inch Shank With Upper And Lower Ball Bearings
SKU: Amana 58183
Availability: InStock

Original price was: $302.40.Current price is: $226.80.

3/4″ SPIRAL FLUSHTRIM COMPRESS

UPC: N/A SKU: Amana 58183 Categories: Amana Tool, Router Bits, Solid Carbide Spiral Flush Trim Compression Router Bits, Trimming Router Bits

Item Description

Plunge-cutting straight with a shank-mounted ball-bearing pilot. Useful for template/pattern routing or parts, joints, internal cuts and can be used in handheld and table-mounted routers. The template is attached to the workpiece and the pilot bearing rides along its edge as the cutting edges rout the workpiece, forming an exact duplicate of the template.

Replacement Parts

Specifications

Diameter (D)	3/4
Cutting Height (B)	1-1/8
Shank (d)	1/2
Overall Length (L)	3-1/2
Replacement Bearing	Top: 47830 Bottom: 47798
Flutes	2

Other Sizes Available

Diameter (D)	Cutting Height (B)	Shank (d)	Overall Length (L)	Replacement Bearing	Flutes	Tool No.
1/2 (12.70mm)	1 (25.40mm)	1/4 (6.35mm)	2-5/8	47706, 47701	2	57175
1/2 (12.70mm)	1 (25.40mm)	1/4 (6.35mm)	3-1/4	47706, 47701	3	58182
7/8 (22.23mm)	1-1/8	1/2 (12.70mm)	3-3/4	47830, 47798	2	57178
7/8 (22.23mm)	1-5/8	1/2 (12.70mm)	4-1/4	47830, 47798	2	58180

Weight	0.32 lbs
