YG1-0541KCN – 5.4 x 57 x 101 – Hss-Ex Hpd-Sus Twist Drill Tin-Coated (Jobbers)

Original price was: $35.55.Current price is: $24.35.

HPD Drill

UPC: N/A SKU: YG1-0541KCN Categories: Drilling, HPD Drill, HSS & Cobalt Drill, YG-1

EDP No.	0541KCN
Description	HSS-EX HPD-SUS TWIST DRILL TiN-COATED (JOBBERS)
Size	5.4 x 57 x 101
Available Qty.	Call for availability

Specifications

Series	DJ544
Long Description	5.4 x 101.0 OAL 120° Point Jobber TiN HSS EX HPD-SUS Drill
Number of Flutes	2
Diameter (inch)	0.2126
Diameter (mm)	5.4
Shank Dia. (inch)	0.2126
Shank Dia. (mm)	5.4
Flute Length (inch)	2.2441
Flute Length (mm)	57
Overall Length (inch)	3.9764
Overall Length (mm)	101
Point Length (inch)	0.0614
Point Length (mm)	1.559
Point Angle	120̊
Helix Angle	38°
Length/ Diameter	Jobber
Shank Tolerance	h7
Coolant Through	Non Coolant
Blank Standard	DIN6535
Coating	TiN
Material	HSS- E
Hole Tolerance	h8
Type	HSS-EX HPD-SUS Twist Drill TiN Coated (Jobber)
Application	Steels,Stainles Steels, Aluminum Copper Alloys
Cutting Direction	Right
System of Measurement	MM
Uses	Designed for drilling in stainless steels, mild steels, aluminum, aluminum alloy, aluminum die cast, copper, copper alloy, etc
Advantages	High helix-sharp cutting edges to avoid built-up and to be suitable for high performance drilling Wide flute and stub length-increasing chip removal and reducing vibration and deflection. High vanadium HSS-EX material with superior TiN coating – higher speed and feed, longer service life High quality-good surface finishes, high productivity.
Taxonomy	Jobber
