YG1-12000951 – SPKR1203EDTR-YG612/SPKR42EDTR – Indexable Milling Insert

Original price was: $26.66.Current price is: $18.25.

SPKR1203EDTR-YG612/SPKR42EDTR — YG-1 Indexable Milling Insert.

Sold in boxes of 10 only — price shown is per insert. Quantity 10 = one box of 10 inserts.

UPC: N/A SKU: YG1-12000951 Categories: Indexable, Indexable, Indexable Insert, YG-1

EDP No.	12000951
Description	SPKR1203EDTR-YG612/SPKR42EDTR
Size/Dimension	SPKR1203EDTR-YG612/SPKR42EDTR
Series	SPKR1203
Package	Box of 10 pieces (price shown per piece)
Available Qty.	Call for availability

Specifications

Series	SPKR
ANSI Code	SPKR42EDTR
ISO Code	SPKR1203EDTR
ANSI	ISO
Shape	Square
# of Cutting Edges	4
Depth of Cut	8
Clearance Angle	11°
IC Tolerance (± inch)	0.003
IC Tolerance (± mm)	0.076
Height Tolerance (± inch)	0.001
Height Tolerance (± mm)	0.025
Thickness Tolerance (± inch)	0.005
Thickness Tolerance (± mm)	0.127
Insert Type	Without clamping hole, no chipbreaker
Insert IC (inch)	0.5
Insert IC (mm)	12.7
Thickness (in)	0.126
Thickness (mm)	3.2
Corner Radius (in)	0.0312
Corner Radius (mm)	0.794
Chipbreaker Application	General Application
Cutting Edge Angle	75°
Wiper Edge Clearance	15°
Edge Condition	Chamfered
Feed Direction	Right hand Insert
Wiper Edge Length	0.055
Grade	YG612
Material	Carbide
Coating Process	PVD
Coating	TiAlN
Type	MILLING INSERT
Application	Steel, Stainless Steel, Super Alloy
System of Measurement	Inch
Application code	P,M,S

Specialized Multi-Nano Coated Grade with high wear resistance and chipping resistance. Special Multi-Nano coating prevent crack and providing predictible tool life. Special universal Grade can acheive stable tool life in any workpiece.
