YG1-52000159 – TDY6E-0.4-GL-YG602G – Indexable Turning Insert

Original price was: $64.19.Current price is: $43.95.

TDY6E-0.4-GL-YG602G — YG-1 Indexable Turning Insert.

Sold in boxes of 10 only — price shown is per insert. Quantity 10 = one box of 10 inserts.

UPC: N/A SKU: YG1-52000159 Categories: Indexable, Indexable, Indexable Insert, YG-1

EDP No.	52000159
Description	TDY6E-0.4-GL-YG602G
Size/Dimension	TDY6E-0.4-GL-YG602G
Material	Carbide
Series	TDY, TDY6
Package	Box of 10 pieces (price shown per piece)
Available Qty.	Call for availability

Specifications

Series	TDY
ANSI Code	TDY6E-0.4-GL
ISO Code	TDY6E-0.4-GL
ANSI	ISO
Shape	Turn Groove
# of Cutting Edges	2
Depth of Cut	10
Clearance Angle	7º
IC Tolerance (± mm)	#VALUE!
Height Tolerance (± inch)	0.002 / -0.0008
Height Tolerance (± mm)	#VALUE!
Thickness Tolerance (± inch)	0.002
Thickness Tolerance (± mm)	0.05
Insert Type	Parting & Grooving insert
Insert IC (mm)	#VALUE!
Thickness (in)	0.2362
Thickness (mm)	5.999
Corner Radius (in)	0.0156
Corner Radius (mm)	0.397
Edge Length (in)	0.7874
Edge Length (mm)	20
Chipbreaker Geometry	GL
Chipbreaker Application	Grooving Low Feedrate
Wiper Edge Clearance	15°
Grade	YG602G
Material	Carbide
Coating Process	PVD
Coating	TiAlN+Tin
Type	PARTING & GROOVING INSERT
Application	Steel, Stainless Steel, Cast Iron, Super Alloys
System of Measurement	Inch
Application code	P,M,K,S

Universal grade for Parting & Groove Turn. Ultra Dense PVD Coating with optimal thermal resistance & strength. Sub-Micron substrate designed for demanding application. YG602G : First Choice for Low Cutting Speed, Soft and Sticky Material with Low Hardness (Gold Color) – YG602 : First Choice for General Application (Violet Color)
