YG1-12000972 – RDKT1604M0-YG612 – Indexable Milling Insert

Original price was: $26.13.Current price is: $17.90.

RDKT1604M0-YG612 — YG-1 Indexable Milling Insert.

Sold in boxes of 10 only — price shown is per insert. Quantity 10 = one box of 10 inserts.

UPC: N/A SKU: YG1-12000972 Categories: Indexable, Indexable, Indexable Insert, YG-1

EDP No.	12000972
Description	RDKT1604M0-YG612
Size/Dimension	RDKT1604M0-YG612
Material	Carbide
Series	RDKT, RDKT1604
Package	Box of 10 pieces (price shown per piece)
Available Qty.	Call for availability

Specifications

Series	RDKT
ANSI Code	RDKT1604M0
ISO Code	RDKT1604M0
ANSI	ISO
Shape	Round
# of Cutting Edges	depends on DOC
Depth of Cut	8
Clearance Angle	15°
IC Tolerance (± inch)	0.002
IC Tolerance (± mm)	0.051
Height Tolerance (± inch)	0.001
Height Tolerance (± mm)	0.025
Thickness Tolerance (± inch)	0.005
Thickness Tolerance (± mm)	0.127
Insert Type	With Screw hole, chipbreaker on one side only
Insert IC (inch)	0.6299
Insert IC (mm)	16
Thickness (in)	0.187
Thickness (mm)	4.75
Corner Radius (mm)	#VALUE!
Insert Diam (in)	0.6299
Insert Diam (mm)	16
Chipbreaker Application	General Application
Cutting Edge Angle	round
Wiper Edge Clearance	15°
Feed Direction	Neutral Insert
Grade	YG612
Material	Carbide
Coating Process	PVD
Coating	TiAlN
Type	MILLING INSERT
Application	Steel, Stainless Steel, Super Alloy
System of Measurement	Inch
Application code	P,M,S

Specialized Multi-Nano Coated Grade with high wear resistance and chipping resistance. Special Multi-Nano coating prevent crack and providing predictible tool life. Special universal Grade can acheive stable tool life in any workpiece.
