| EDP No. | DH501059 |
|---|---|
| Description | CARBIDE DREAM DRILL FOR HIGH HARDENED MATERIAL (HRc50 ~ HRc70) TIALN COATED |
| Size | Y x 10.26 x 1/2 x 2-1/2 x 4-3/8 |
| Available Qty. | Call for availability |
Specifications
| Series | DH501 |
|---|---|
| Long Description | 0.404 x 4.375 OAL 140° Point 3 X D TiAlN Non Coolant High Performance Carbide Dream Drill Hardened Steels |
| Number of Flutes | 2 |
| Letter Size | Y |
| Diameter (inch) | 0.404 |
| Diameter (mm) | 10.2616 |
| Shank Dia. (inch) | 0.5 |
| Shank Dia. (mm) | 12.7 |
| Flute Length (inch) | 2.5 |
| Flute Length (mm) | 63.5 |
| Overall Length (inch) | 4.375 |
| Overall Length (mm) | 111.125 |
| Point Length (inch) | 0.0735 |
| Point Length (mm) | 1.867 |
| Point Angle | 140° |
| Helix Angle | 15° |
| Length/ Diameter | 3 X D |
| Shank Tolerance | h6 |
| Coolant Through | Non Coolant |
| Coating | TiAlN |
| Material | Carbide |
| Hole Tolerance | h7 |
| Type | High Hardened Steels (HRc50-HRc70) |
| Application | Hardened Steel,Chilled cast Iron |
| Cutting Direction | Right |
| System of Measurement | Inch |
| Application Code | H |
Drilling for High Hardened Steels; Quenched Steels, Tempered Steels (under HRc70),Special geometry design for Hardened Steels, Minimum of cutting load through special thinning, Performing good chip removal and powerful drilling
