54127 Carbide Tipped Ogee Fillet 3/8 Radius x 2-1/4 Dia x 15/16 x 1/2 Inch Shank

Amana 54127 Carbide Tipped Ogee Fillet 3/8 Radius x 2-1/4 Dia x 15/16 x 1/2 Inch Shank

Name: Amana 54127 Carbide Tipped Ogee Fillet 3/8 Radius x 2-1/4 Dia x 15/16 x 1/2 Inch Shank
SKU: Amana 54127
Availability: InStock

Original price was: $128.10.Current price is: $96.08.

CLASSICAL OGEE 1/2 SHANK

UPC: 738685941270 SKU: Amana 54127 Categories: Amana Tool, Ogee Router Bits, Profiling Router Bits, Router Bits

Item Description

This ogee pattern has a step at the end of the concave portion of the curve. Using the optional 3/8″ bearing #47702 (sold separately) produces a profile with a fillet at the convex end of the curve. Use in a handheld or table-mounted router.

Maximum RPM 18,000.

Replacement Parts

Tool No.	Bearing(s)	Optional Bearing(s)	Screw	Dust Shield	Flat Washer
54127	47706	47702	67096	67098	67202

Specifications

Diameter (D)	2-1/4
Radius (R)	3/8
Cutting Height (B)	15/16
Shank (d)	1/2
Overall Length (L)	2-7/8
Replacement Bearing	47706
Flutes	2

Other Sizes Available

Diameter (D)	Radius (R)	Cutting Height (B)	Shank (d)	Overall Length (L)	Replacement Bearing	Flutes	Tool No.
1-3/8	5/32 (3.97mm)	1/2 (12.70mm)	1/4 (6.35mm)	2-1/16	47706	2	54110
1-3/8	5/32 (3.97mm)	1/2 (12.70mm)	1/2 (12.70mm)	2-1/2	47706	2	54112
1-5/8	1/4 (6.35mm)	3/4 (19.05mm)	1/2 (12.70mm)	2-5/8	47706	2	54114

Weight	0.56 lbs

Brand

Amana Tool

Amana Tool® is an industry leader for over 40 years specializing in industrial quality solid carbide, insert carbide and carbide-tipped cutting tools for the woodworking, plastics, aluminum, composite and metal industry. They provide many solutions for manufacturers, fabricators, display and cabinet professionals as well as hobbyists. Amana Tool’s full line of industrial-quality cutting tools includes saw blades, router bits, shaper cutters, boring bits and much more.
