YG1-12000949 – RDKW1204M0-YG612 – Indexable Milling Insert

Original price was: $23.21.Current price is: $15.90.

RDKW1204M0-YG612 — YG-1 Indexable Milling Insert.

Sold in boxes of 10 only — price shown is per insert. Quantity 10 = one box of 10 inserts.

UPC: N/A SKU: YG1-12000949 Categories: Indexable, Indexable, Indexable Insert, YG-1

EDP No.	12000949
Description	RDKW1204M0-YG612
Size/Dimension	RDKW1204M0-YG612
Material	Carbide
Series	RDKW, RDKW1204
Package	Box of 10 pieces (price shown per piece)
Available Qty.	Call for availability

Specifications

Series	RDKW
ANSI Code	RDKW1204M0
ISO Code	RDKW1204M0
ANSI	ISO
Shape	Round
# of Cutting Edges	depends on DOC
Depth of Cut	6
Clearance Angle	15°
IC Tolerance (± inch)	0.003
IC Tolerance (± mm)	0.076
Height Tolerance (± inch)	0.001
Height Tolerance (± mm)	0.025
Thickness Tolerance (± inch)	0.005
Thickness Tolerance (± mm)	0.127
Insert Type	With Screw hole, no chip breaker
Insert IC (inch)	0.4724
Insert IC (mm)	12
Thickness (in)	0.189
Thickness (mm)	4.801
Corner Radius (mm)	#VALUE!
Insert Diam (in)	0.472
Insert Diam (mm)	11.989
Chipbreaker Application	General Application
Cutting Edge Angle	round
Wiper Edge Clearance	15°
Edge Condition	Chamfered
Feed Direction	Neutral Insert
Grade	YG612
Material	Carbide
Coating Process	PVD
Coating	TiAlN
Type	MILLING INSERT
Application	Steel, Stainless Steel, Super Alloy
System of Measurement	Inch
Application code	P,M,S

Specialized Multi-Nano Coated Grade with high wear resistance and chipping resistance. Special Multi-Nano coating prevent crack and providing predictible tool life. Special universal Grade can acheive stable tool life in any workpiece.
